  Wind Turbines 350 kW Technical Data    Search





Operating Data


Rotor diameter

33.4 m
Hub height

50/60/70 m
Installed elec. output

350 kW
Cut-in wind speed

 3.5 m/s
Rated wind speed

 14 m/s
Cut-out wind speed

 25 m/s
Survival wind speed

 67 m/s


350 kW

System Design

Technical Description
Salient Features
Technical Data
Power Curve






Rotor


Blade

LM 15.4, NACA 63.2XX
Swept area

876.13 m²
Rotational Speed

24 / 32 rpm

Rotor material Glass-fibre reinforced plastic
Regulation Stall regulated







Generator


Type

Asynchronous generator, 8/6 pole
Rated output

100 / 350 kW
Rotational speed

756 / 1006 rpm
Frequency 50 Hz







Gearbox


Type

Integrated 3-stage helical spur, splash lubricated
Ratio

31.5 : 1
Type of cooling Oil cooling system







Yaw System


Drive

2 active electrical yaw motors

Bearings

Polyamide slide bearings







Braking System


Aerodynamic brake

Hydraulic control of the blade tip
Electrical brake

Spring applied, hydraulically
released disk brake
Mechanical brake

Centrifugally operated hydraulic valve







Control Unit


Type

Microprocessor-based; indicating actual operations conditions; remote control option








Tower


Type

Freestanding; lattice tower; hot dip galvanized







Erection


Type

With crane
